Specifications

• ENGINE

  add remove
  • Engine Type:
    Parallel Twin
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Liquid
  • Displacement (cc):
    999
  • Horsepower (bhp):
    100
• DRIVE LINE

  add remove
  • Driveline Type:
    Selectable 4X2 / AWD
  • Number Of Driveline Modes:
    3
  • Rear Unlocking Differential:
    No
  • Driveline Brand:
    On-Demand™
  • Limited Slip Differential Location:
    Center
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (mm):
    3000
  • Width (in):
    64
  • Height (in):
    75
  • Wheelbase (in):
    83
  • Ground Clearance (in):
    13.5
  • Dry Weight (lbs):
    1690
  • Payload Capacity (lbs):
    1100
  • Towing Capacity (lbs):
    1500
  • Fuel Capacity (gal):
    9.5
  • Engine Displacement to Weight (cc):
    0.59
  • Front Tread Width (in):
    64
  • Rear Tread Width (in):
    64
• STEERING

  add remove
  • Steering Control:
    Steering Wheel
  • Steering Type:
    Power
• SUSPENSION

  add remove
  • Front Suspension Type:
    Independent Double A-Arm
  • Front Travel (in):
    14
  • Rear Suspension Type:
    Independent
  • Rear Travel (in):
    14
  • Number Rear Shock Absorbers:
    2
  • Rear Suspension Brand Name:
    Walker Evans®
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Front Tire (Full Spec):
    Pro Armor® Crawler XGF: 30 x 10-15
  • Rear Tire (Full Spec):
    Pro Armor® Crawler XG: 30 x 10-15
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
• STORAGE

  add remove
  • Bed Length (in):
    27.5
  • Bed Width (in):
    43.1
  • Bed Height (in):
    11.6
  • Bed Capacity (lbs.):
    600
  • Bed Volume (m3):
    0.1
  • Cargo Bed Tilt:
    Yes
• INSTRUMENTATION

  add remove
  • Fuel Level Warning Type:
    Gauge
  • Temperature Warning Type:
    Light
