Specifications

• ENGINE

  add remove
  • Engine Type:
    V Twin
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Torque (Ft Lbs):
    47
  • Valves:
    4
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    SOHC
  • Bore (in):
    3.35
  • Stroke (in):
    2.72
  • Displacement (cc):
    783
  • Compression Ratio:
    10.7:1
  • Carburetion Brand:
    Mikuni
  • Fuel Injector:
    Yes
  • Carburetor:
    No
  • Carburetion Type:
    Fuel Injected
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
  • Reverse:
    Yes
  • Adjustable Throttle:
    Not Available
  • Primary Drive (Rear Wheel):
    Shaft
• DRIVE LINE

  add remove
  • Driveline Type:
    Selectable 4X2 / 4X4
  • Number Of Driveline Modes:
    2
  • Rear Unlocking Differential:
    Yes
  • Differential Lock Location:
    Front
  • Limited Slip Differential Location:
    Front
  • Rear Solid Axle:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    60
  • Height (in):
    77.8
  • Wheelbase (in):
    85.6
  • Turning Radius (ft):
    16.7
  • Ground Clearance (in):
    11.2
  • Payload Capacity (lbs):
    1109
  • Towing Capacity (lbs):
    1300
  • Fuel Capacity (gal):
    7.9
  • Wet Weight (lbs):
    1605.2
• SUSPENSION

  add remove
  • Front Suspension Type:
    Double A-Arm
  • Rear Suspension Type:
    Independent
  • Number Rear Shock Absorbers:
    2
  • Air Adjustable:
    No
  • Center Suspension:
    Not Available
  • Adjustment Type:
    Shock Mounted Adjustment
  • Rear Adjustable Shock / Spring Pre-Load:
    Yes
  • Front Travel (in):
    8
  • Rear Travel (in):
    8.3
  • Front Suspension Brand Name:
    Fox® Podium
  • Front Adjustable Fork Pre-Load:
    Yes
  • Rear Suspension Brand Name:
    Fox® Podium
  • Rear Stabilizer Bar:
    Yes
• WHEELS & TIRES

  add remove
  • Front Tire (Full Spec):
    Maxxis® Bighorn: 26 x 9-12
  • Rear Tire (Full Spec):
    Maxxis® Bighorn: 26 x 11-12
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Dual Hydraulic Disc
  • Rear Brake Type:
    Sealed Oil Bath Multi-Disc
  • Anti-Lock Brakes:
    Not Available
  • Front Brake Diameter (in):
    7.9
• TOWING & HAULING

  add remove
  • Rear Hitch:
    Standard
  • Draw Bar:
    Optional
  • Winch:
    Optional
  • Tilt:
    No
  • Removable Tailgate:
    No
  • Removable Sides:
    No
• STORAGE

  add remove
  • Bed Length (in):
    17.9
  • Bed Width (in):
    47.6
  • Bed Height (in):
    8.7
  • Cargo Bed Material:
    Polyethylene
  • Bed Capacity (lbs.):
    249
  • Bed Volume (ft3):
    4.3
  • Helmet Storage:
    Not Available
  • Gun Scabbard:
    Not Available
  • Number Of Cupholders:
    4
  • Lockable Storage:
    Not Available
  • Cargo Bed Storage:
    Optional
• SEATS

  add remove
  • Seat Type:
    Bucket
  • Seat Material:
    Vinyl
  • Number Of Seats:
    4
  • Number Of Rows:
    2
